UP 2030 2000/30/24

Ideal for small and medium farms.

Maximum Productivity

With 7,580 kg (empty machine) when equipped with a 24m boom it allows to operate with low pressure on the tires, reducing soil compaction and increasing crop productivity, all with low fuel consumption; less weight to pull the equipment. Simplicity and handling for carrying out operations; everything located on one side of the equipment.

Strength and performance

4x4 hydrostatic transmission system with automatic traction control; integrated with the 198 hp diesel engine and ideal weight distribution between the axles, it allows spraying on terrain with a slope of up to 30%; the system automatically identifies the need for traction control in the vehicle without the need for the operator to act; more comfort and precision in the spraying operation, reducing fuel consumption.

Operational Efficiency

The Uniport 2030 works at speeds of up to 25 km/h in the spraying operation and 40 km/h in displacement, when equipped with 30m booms and compared to equipment with 28m, it provides up to 5% increase in operational efficiency and reducing crop dents up to 7% daily income can reach up to 535 hectares p/day.
Technical Specifications:
tank

material polyethylene



length 10m



nozzles
atomizer model jac 80-025
total 16 nozzles
total 16 nozzles








material polyethylene







regulator type












































Length
7.60 m (24 m) | 7.73 m (30 m)



Maximum Width
3,20 m



Height
3,93 m (13.6 x 38) | 3,89 m (340/85 R38)



Length between Axis
3,80 m



Ground Clearance
1,60 m (13.6 x 38)
1,56 m (340/85 R38)


Track Width Adjustment
8.5 up to 10.3 ft | Series Manual or hydraulic drive
1,56 m (340/85 R38)


Weight (empty machine)
7.580 kg (24 m) 8.665 kg (30 m)











































Fuel Tank
Capacity 275 Liters



Engine
Model Cummins QSB 4.5
Model Cummins QSB 4.5
Maximum Power 198 hp @ 2.200 rpm
Fuel Diesel or Biodiesel B20
Transmission
4x4 hydrostatics with independent electronic traction control



Suspension
Independent, with pneumatic springs and hydraulic shock absorbers.



Tires
13,6 x 38" (series)
IF340/85 R38 (optional)




















































Lightbar
Omni 700 (series)
GFX-750 (Optional)


Hydraulic autopilot
Omni 700 (series)
GFX-750 (optional)


GPS signal corrections available
TerraStar C PRO or RTK (Omni 700)
RTX or RTK (GXF-750)


Automatic section controller
4 or 8 Sections



Operations Repeater
Agis (only for the Omni 700)



Temperature and humidity sensor
(Series)



Ekos
Solutions for agricultural operation management (Series)
